Coil Selection Software

Modine’s selection software, COILS, makes it possible to select and size the ideal Air Blast Cooler for any installation. COILS has been rigorously tested for reliability and is a highly flexible tool.

Coils_software_main

Output consists of a print-out of technical data and a dimensional drawing of the selected cooler. To meet the needs of the varied and demanding projects our customers embark upon, our Air Blast Coolers come in a vast range of dimensions and configurations. To help navigate through the options, we recommend using COILS or contacting our sales staff as a first step.

Coils_Software_selection_logo

Variables to be considered while sizing and selecting include:

  • Cooling capacity
  • Ambient temperature
  • Sound level (fan speed)
  • Cooler size
  • Fan motor power supply
  • Environmental conditions
  • Number of fans, tube rows
  • Liquid flow rate, etc.

Please enter your contact information

    FOR CUSTOMER SPECIFIC SOFTWARE
    Please enter your Customer Code or contact us for questions.
    E-mail: coilselection@modine.com

    DOWNLOAD INFORMATION

    Standard program, no need for a customer code Customer specific, requires customer code
    Heating/cooling coils Ventilation products
    Heat recovery systems Industrial products
    Unit air heaters/coolers
    Dry coolers
    COILS SELECTION SOFTWARE INCLUDES
    coils for heating or cooling air with water, steam, evaporating or condensing media
    liquid coupled heat recovery systems
    unit air heaters
    dry coolers
    THE SOFTWARE COMPRISES THE FOLLOWING PRODUCTS:
    Heat Exchangers Selection of coils for heating or cooling of air with water plus any freeze protection used, evaporation/condensation media or steam.
    Air unit heaters ATD & LVD The program handles liquid coupled heat recovery systems with up to 20 input and exhaust coils. Input data to be specified is airflow, temperature and humidity for each coil and required temperature efficiency, if any. It is also possible to specify required coil dimensions. The program presents the performance under the dimensioning conditions but also for three other surrounding temperatures. In case an anti-freeze control is needed, the performance of the system under the adjusted conditions will be presented as well. If required, the program will also present a system chart. This system chart suggests dimensioning of the system including required tube dimensions, pump, vents and control devices. Finally, the program offers a tool for estimating the profitability considering location, operating time, investment costs, energy price etc.
    Dry cooler COOL Specify requested performance including any demands of noise limits. The program will present a number of alternatives, which can be easily compared in regard of cooling capacity, liquid pressure drop, noise and price. A separate noise calculation may be made for a plant including a number of coolers.
    Transformer oil cooler ALFA, BETA & CETA Specify required performance including any demands of noise limits. The program will present a number of alternatives, which can be easily compared in regard of cooling capacity, liquid pressure drop, noise and price.
    Generator/Motor Coolers The focus is laid on consideration of polluted environments. In case of pollution, a certain over dimensioning of the surface is often made in order to fulfil the cooling requirements. Alternatively, a fouling factor may be specified for the inner or outer surface of the coil. An optional choice is hydrogen gas as outer medium instead of air.
    Two-circuit coolers Specify required performance, some basic data and suggested number of coolers. The program will inform you, should the number of coolers not be sufficient.
